Cub cadet hydraulic pump replacement

Cub cadet hydraulic pump replacement DEFAULT

Cub Cadet is a premium line of outdoor power equipment, established in 1961 as part of International Harvester. During the 1960s, IH initiated an entirely new line of lawn and garden equipment aimed at the owners rural homes with large yards and private gardens. There were a wide variety of Cub Cadet branded and after-market attachments available; including mowers, blades, snow blowers, front loaders, plows, carts, etc. Cub Cadet advertising at that time harped on their thorough testing by "boys - acknowledged by many as the world's worst destructive force!". Cub Cadets became known for their dependability and rugged construction.

MTD Products, Inc. of Cleveland, Ohio purchased the Cub Cadet brand from International Harvester in 1981. Cub Cadet was held as a wholly owned subsidiary for many years following this acquisition, which allowed them to operate independently. Recently, MTD has taken a more aggressive role and integrated Cub Cadet into its other lines of power equipment.

This website and forum are not affiliated with or sponsored by MTD Products Inc, which owns the CUB CADET trademarks. It is not an official MTD Products Inc, website, and MTD Products Inc, is not responsible for any of its content. The official MTD Products Inc, website can be found at: http://www.mtdproducts.com. The information and opinions expressed on this website are the responsibility of the website's owner and/or it's members, and do not represent the opinions of MTD Products Inc. IH, INTERNATIONAL HARVESTER are registered trademark of CNH America LLC

All material, images, and graphics from this site are the property of www.onlycubcadets.net. Any unauthorized use, reproductions, or duplications are prohibited unless solely expressed in writing.

Cub Cadet, Cub, Cadet, IH, MTD, Parts, Tractors, Tractor, International Harvester, Lawn, Garden, Lawn Mower, Kohler, garden tractor equipment, lawn garden tractors, antique garden tractors, garden tractor, PTO, parts, online, Original, 70, 71, 72, 73, 76, SO76, 80, 81, 86, 100, 102, 104, 105, 106, 107, 108,109, 122, 123, 124, 125, 126, 127, 128, 129, 147, 149, 169, 182, 282, 382, 482, 580, 582, 582 Special, 680, 682, 782, 782D, 784, 800, 805, 882, 982, 984, 986, 1000, 1015, 1100, 1105, 1110, 1200, 1250, 1282, 1450, 1512, 1604, 1605, 1606, 1610, 1615, 1620, 1650, 1710, 1711, 1712, 1806, 1810, 1811, 1812, 1912, 1914.

Sours: https://www.onlycubcadets.net/forum/showthread.php?t=1408

Cub Cadet Hydraulic Pump Replacement 02004242P

Cub Cadet Hydraulic Pump Replacement 02004242P

Your Cub Cadet hydraulic pump replacement converts hydraulic energy into mechanical energy so your Cub Cadet mower runs efficiently.

This part replaces:

Cub Cadet Hydraulic Pump Replacement 02004242P – Please use our Free MTD Cub Cadet Parts Look Up to verify this is the correct part for your MTD Cub Cadet model and serial number. Not able to locate a specific part? Contact Us!  Need parts for another brand?  Check out our full line of brands here!

Where Used: Part Number 02004242P
Model Name Diagram
56B36D4K750 Tank Ride-On Sprayer-Spreader Hydro Pump Assembly
RECON 48 (53AH8ST3050) 23HP Kohler Hydro Hose & Pump Assembly
RECON 60 (53AH8ST5050) 25HP Kohler Hydro Hose & Pump Assembly
Tank 48 (53AH8STB050) 23HP Kohler Hydro Hose & Pump Assembly
Tank 60 (53AH8STD050) 25HP Kohler Hydro Hose & Pump Assembly

Simple Processing

We recommend you verify which part is correct for your particular Cub Cadet unit. First, enter your model number by using our convenient Parts Lookup and Part Diagrams. Secondly, select the appropriate diagram. Third, select the appropriate part and quantity, then add it to your cart. However, should you be unable to find what you are looking for, please contact us via email or 800-866-5473.

After your order is placed, we will keep you informed of its status including notification when it ships. More importantly, our growing partnership with UPS allows us to offer reasonable shipping rates throughout the U.S.  We proudly offer free shipping on orders of $75 or more however, over sized packages will have a small additional charge.

Sign up now to receive our newsletter filled with informative lawn care tips and lawn mower maintenance tips. Additionally, you will receive special offers reserved for our most valued customers.  Most importantly, it is completely hassle free and without strings attached.  However, you may unsubscribe to our emails at anytime.  If you sign up now, you will receive a 5% discount on your first order.

Who Are We?

Powered by Andersons’ Sales & Service, Inc., we have everything you need to keep your Cub Cadet mower running right. If you live in the Louisville Metropolitan Area, you can pick up your order at one of our 3 convenient locations in Louisville, Crestwood, and Madison, Indiana.  We have been in business for over 40 years and enjoy serving our customers from all 50 states in the U.S. Our Mission is Making Your Life Easy, Quality Products and Quality Service.

Thank you for your patronage, Happy Shopping!

Sours: https://cadetmowerparts.com/product/cub-cadet-hydraulic-pump-replacement-02004242p/
  1. Mullein leaf tea side effects
  2. What a feeling lyrics
  3. Vw touch up paint black

M48 Tank

4.23. When the fluid is between 160-210 deg. f.

(71-90 deg. c.) apply full forward drive pressure

to the lap bar with the engine running at full

speed (3600 RPM) while an assistant closes the

valve to the point where pressure reaches 300

PSI (21 Bar.). See Figure 4.23.

10 GPM

FLOW

300 PSI

Figure 4.23

NOTE: It may be necessary to over-shoot 300

PSI slightly, then open the valve to reduce pres-

sure to 300 PSI.

4.24. Take note of the reading on the flow meter por-

tion of the test kit when the pressure gauge

reads 300 PSI.

4.25. Continue closing the valve until the pressure

reading reaches 1,100 PS I (76 bar.). Take note

of the flow reading. See Figure 4.25.

1100 PSI

Figure 4.25

4.26. Subtract the 1,100 PSI flow reading from the 300

PSI flow reading. The resulting figure is called

"flow droop".

CONTROL

CONSOLE INSET:

3600 RPM

SPINNING

CLOSE VALVE TO

BUILD PRESSURE

9 GPM

VALVE CLOSED

FURTHER

4.27. Interpretation: flow droop greater than 1.5 GPM

indicates a pump that is not performing as well

as it should.

NOTE: A blocked filter may account for some

loss of performance.

4.28. Within the two year Cub Cadet Commercial war-

ranty period, replace the pump if it does not per-

form as specified and all other factors have been

eliminated.

4.29. If a hydro pump requires repair, refer to Hydro-

Gear publication "BLN-51337" for complete ser-

vice instructions.

4.30. If the hydro pump and all other factors are O.K.,

replace the hydro motor.

NOTE: The hydro motor is not serviceable.

Replace it as a unit if it fails.

5.

REPLACING THE HYDRO PUMP

5.1.

If the cutting deck is currently on the unit,

remove it.

5.2.

Safely lift and support the rear of the tank.

5.3.

Remove the rear wheels using a 3/4" socket.

5.4.

Tilt the seat up, and disconnect the negative bat-

tery cable.

5.5.

Remove the screen that covers the opening over

the cooling fans on the hydro pump to be

removed using a 3/8" wrench. See Figure 5.5.

REMOVE DEBRIS SCREEN

6

Figure 5.5

Sours: https://www.manualslib.com/manual/33906/Cub-Cadet-M48-Tank.html?page=10
12-19-13 Cub Cadet hydro pump question from Joe K

Cub Cadet hydro pump

Ok long story short. Right side of zero turn rider was getting weak and would stop pulling after 30-45 mins. So I started looking around for the model # so I could at least soo how much the part,(s) I need would be. I can not find a model # or anything on this mower. There is a sticker under the seat that says 01 oct 12. So I'm guessing it was made in 2001 october. I only got the mower last year from a co-worker, and it only has 500 hrs on it. There aren't any stickers under or on the floor board. I ever called cub cadet, and talked to a guy there and gave him the #'s that were under the seat. There is a sticket under seat that says S# ..... V#..... He said he thought it was a tank but he couldn't be sure. Anyway, it has a 23HP Kawasaki engine, zero turn rider. The seat does say cub cadet commercial. What I'm wanting to know is if I post some pics could someone help me out? I jus tneed to know th emodel number or the pump brand maybe. thanks for the help

Sours: https://www.lawnmowerforum.com/threads/cub-cadet-hydro-pump.8420/

Replacement pump cadet cub hydraulic

Note:  As you read through this article you’ll notice that I have places where I need to post additional pictures.   As I get those pictures I’ll add them to the article.

I’ve seen a lot of questions about the narrow frame hydraulic pumps that Cub Cadet used on their garden tractors. I’ve worked on quite a few of these so I thought I’d write an article on what I know about them. Fortunately, I don’t have one that needs working on right now, but I’ll use pictures and information that I’ve gained in the past for this article. The next time I have to work on one, I’ll get some pictures as I go – if I don’t get in too big of a hurry as I usually do!! The pumps generally don’t show much wear but require replacement of two seals that start leaking over time. The major fault is the failure of the pump gears. This is often caused by the failure of the valve return spring. If a section of the spring breaks and works its way into the gears, the gears are toast. For that reason, if you have reason to suspect a spring failure, quit using the pump and replace the spring.

The pump used on Cub Cadet was apparently manufactured for Cub Cadet by Hein Werner. These pumps with some major and minor variations were used on a variety of garden tractors. I’ve collected pumps from Toro, Wheel Horse, and Bolens as well as Cub Cadet. I’ll include some pictures and discussion about these variations after talking about the overhaul rather than making this discussion too long winded.  (The Wheel Horse discussion got so long that I’ve moved it to it’s own section.)

A good friend, Larry Goss, sent me some additional information after I first wrote this article that I’ve since included in my discussion.  Larry has a Hein Werner pump on a Power King tractor.

Begin by removing the pump from the bracket assembly.

(Click on image for larger view)



Begin the process by removing the nut that holds the reservoir in position. The nut is No. 52 in the previous parts diagram. Part No. 53 in the diagram is a washer and seal that seals the end of the hydraulic reservoir. On the majority of pumps I’ve worked on, this seal is stuck to the end of the reservoir. Don’t try to slide the reservoir off. Rotate it so that you “unscrew” the seal from the threads so that you won’t mess it up. The seal is one of those NLA things.

hydraulic pump pic 2

I’ve only had to remove the valve (No. 30) on one pump that I’ve worked on. Generally I’ve found that this part doesn’t leak. If you have to remove it, I think it’s easier to remove the external snap ring and force it inward rather than trying to remove the two roll pins on the inside. But be aware that the valve and pump body are made of mild steel and it’s easy to mar the surfaces. If you’re going to remove the valve, unscrew the control arm from the valve body and carefully remove the return spring on the inside surface. After removing the snap ring thoroughly clean the outer end of all paint and debris. I used a plastic mallet to gently tap the valve inward on the one that I did. I ordered a new O-ring from a Cub Cadet dealer (Part Number IH-707253-R1   1-1/4 X 1-1/2 X 1/8 O-ring). I do know that it was a tight fit and the valve was much stiffer after I replaced the O-ring.  (Larry tells me the O-ring is an Amp-121.)

The three things I replace are the drive shaft seal (47), the reservoir gasket (35), and the valve spring (41).

The valve spring is NLA from Cub Cadet, but there are several places that now carry a replacement — Part No.  IH-386371-R1.  (You can find them from many of the sponsor’s of IHCubCadet.com.  This spring can be also be ordered from JC’s Farm &Garden Supply mentioned in the Wheel Horse article.  They also carry replacement  gears.  They have the replacement spring for the pump used on Cub Cadet, Part No. 5281.)

hydraulic pump pic 3hydraulic pump pic 4























I replace the shaft seal with two seals as sort of double insurance.

hydraulic pump pic 5

The seals are small and it’s easy to get two of them in the shaft bore. But be careful you don’t push them in so far they cover the return drain hole located at the back of the bore. You should be able to pick up the seals at any bearing supply store.

Since the reservoir seal is also NLA from Cub Cadet, I use a replacement from McMaster Carr. Order: http://www.mcmaster.com/#catalog/119/3482/=l3rdnd , Item No. 4061T269.

hydraulic pump pic 6

They’re a little taller than the original seal, but they work well.

hydraulic pump pic 7There’s two gears that pump the oil through the pump.  One gear is connected to the input shaft, and the other is an “idler” gear.  I’ve never had to replace the bearing in the idler gear, but Larry tells me it’s an Oilite bushing ISO B060806.  It seems to me since this gear runs in oil, a solid bushing should work just as well, but with the part number listed any bearing supply store should be able to come up with the necessary dimensions.

hydraulic pump pic 8hydraulic pump pic 9























And that’s about it for now until I have to rebuild another one and get some more pictures. Don’t forget to “screw” the reservoir back on to avoid ruining the seal. And, by the way, I also figured that if I screwed up that seal, I’d just cut out a new one from neoprene and back it up with a flat washer.

I mentioned earlier that several tractors used the same pump. In most cases the “guts” of the pump are basically the same, but the mounting is different. If you want to use one of these other pumps as a replacement for your tractor, make sure it turns in the correct direction. Several garden tractors use a pump that turns in the opposite direction of the one used on the Cub Cadet. You’ll notice on the pump end there’s an arrow that indicates the direction the pump must rotate to operate.

hydraulic pump pic 10

The picture above is a Wheel Horse pump. Notice that the input shaft is on the right and indicates a counterclockwise rotation — the same as a Cub Cadet.

hydraulic pump pic 11

I don’t know what brand of tractor the pump above belongs to, but notice the input shaft is on the left and the arrow indicates a clockwise rotation.









I also had a pump that had a tube fastened to the return inlet.

hydraulic pump pic 13hydraulic pump pic 14

























The long tube seems like a good idea to me since it would prevent a broken spring from getting into the gears.  I don’t know what kind of garden tractor this pump was manufactured for, but notice in the right hand picture that this bracket is made for a pump that rotates in the clockwise direction and won’t work on a Cub Cadet.

There’s another difference that I’d forgotten about, but Larry reminded me.  One of the hydraulic pumps I worked on had needle bearings for the input shaft.  All the Cub Cadet pumps I’ve worked on had a steel input shaft in a steel bore.  Larry tells me that all Power King pumps contain needle bearings.

hydraulic pump pic 15You should be able to make out the needle bearings in the picture above.  (You might also just be able to make out that oil return hole on the right hand side of the bore that I mentioned earlier.)  Larry tells me that a replacement needle bearing is a Torrington Bearing KOYB88.

As always, if you have any questions or comments you can contact me through this website.

















































Last Modified On: 2017-03-25 19:46:05

Sours: http://www.cubcadetman.com/cc/how-tos/hydraulic-pumps/2013/01/working-on-narrow-frame-hydraulic-pumps/
12-19-13 Cub Cadet hydro pump question from Joe K

Removal and Replacement of the Hydraulic Steering Pump

Prior to removing the steering pump, it is necessary to

remove the fender assembly.

CAUTION: Slowly remove the hydraulic lines from the

hydraulic steering pump. Test for pressure in the lines

before removal.

1. Place an oil pan directly under the hydraulic

steering pump. This will catch the hydraulic fluid

that will be drained from the lines and the pump.

2. Remove all four of the hex head tapp screws from

the drive shaft to the pump adapter using a 3/8

socket.

NOTE: Removal of the drive shaft from the pump

adapter is necessary to allow access to the four

hydraulic steering pump mounting bolts.

Pump

Adapter

Tap

Screw

FIGURE 1.

3. Remove both hex cap screws and lock nuts from

the tilt wheel coupling using a 7/16 wrench and a

7/16 socket. See figure 2.

FIGURE 2.

K&T Saw Shop 606-678-9623 or 606-561-4983

www.mymowerparts.com

4. Raise the upper steering shaft. See figure 3.

5. Remove the lower steering shaft from the

6. Slide the drive shaft towards the left frame rail.

Tap

Screws

FIGURE 3.

7. Write down the exact locations of all the hydraulic

Drive

8. Remove both hex cap screws from the steering

Shaft

9. Remove the port plate from the hydraulic lines.

Upper

Steering Shaft

Tilt Wheel

Coupling

Hex Cap

Screws

FIGURE 4.

10 - 1

hydraulic steering pump. See figure 3.

NOTE: The lower steering shaft is splined on

each end and requires lubrication prior to

reassembly.

NOTE: Be careful not to dislodge the blue barrels

on each end of the drive shaft.

Upper

Steering

Bottom

Shaft

Coupling

Sleeve

Half

Bearing

Drive

Shaft

tubes. See figure 4.

pump port plate using a 13mm wrench.

NOTE: Pivot the top edge of the port plate

backward (towards the left frame rail), bringing

the plate to horizontal. Push the port plate up and

rotate the port plate counter-clockwise 90

degrees using the main pressure line as the pivot

point. Slide the port plate towards the left frame

rail until the port plate clears the hydraulic lines.

Steering Pump to Rear

Charge Pump to

Steering Pump

Port Plate

Steering Pump

to Front of

Steering

From Steering

Cylinder

Pump to

Auxiliary

Valve

Cub Cadet 3000

Lower

Steering

Shaft

of Steering Cylinder

Steering

Pump to

Charge

Pump

Sours: https://www.manualslib.com/manual/741787/Cub-Cadet-3000-Series.html?page=62

Now discussing:

We service Cub Cadet hydrostatic pumps.

Cub Cadet Hydraulic Pump Repair Center is a Cub Cadet Hydraulic Pump one stop shopping for all Cub Cadet Hydraulic Pumps. We offer Cub Cadet Pumps and Cub Cadet Hydraulic Pump Repair, Cub Cadet Hydraulic Pump Exchange, New Cub Cadet Hydraulic Pumps and We Sell Cub Cadet Hydraulic Parts for Cub Cadet Hydraulic Pump Repair. We offer Repair for all Cub Cadet Hydraulic Motors. We offer Sundstrand, Danfoss, Eaton, Rexroth, Vickers, Cessna, Dynapower, Uchida and Kawasaki hydraulic pump repair for Cub Cadet products.

Cub Cadet Hydraulic Pump Repair Center and Cub Cadet Hydrostatic Pump Repair Center offers Cub Cadet pumps. We also sell Hydraulic Parts for Cub Cadet. We offer Repair for Cub Cadet Hydraulic Motors, Cub Cadet hydrostatic Motors, Cub Cadet    Hydraulic Drives, Cub Cadet Hydraulic Pump Components, Cub Cadet Hydraulic Pump and Cub Cadet Hydraulic Equipment and all foreign Cub Cadet hydraulic pumps, Hydraulic Pumps, Cub Cadet

We also offer John Deere Excavator Hydraulic Pumps, Rexroth Excavator Hydraulic Pumps, Dynapower Excavator Hydraulic Pumps, Kawasaki Excavator Hydraulic Pumps, Vickers Excavator Hydraulic Pumps, Cessna Excavator Hydraulic Pumps, Denison Excavator Hydraulic Pumps, Link-Belt Excavator Hydraulic Pumps, Hydraulic Excavator Pumps, and Excavator Hydraulic Motors. We repair Sundstrand, Eaton, John Deere, Rexroth, Dynapower, Kawasaki, Vickers, Cessna, Denison, Link-Belt, Hydraulic pumps or Hydrostatic Pumps. We pay top price for Excavator Hydraulic Pumps, Hydraulic Excavator Pumps and Excavator hydraulic motors, rebuilt Main Cub Cadet Hydraulic Pumps.

We exchange Cub Cadet Hydraulic Pumps and we offer an option to save cash, an economic solution to purchasing OEM parts. Our remanufactured Cub Cadet Hydraulic Pumps and Cub Cadet Hydrostatic Pumps are rebuilt using new internal   Hydraulic Pump Parts and Cub Cadet Hydraulic Pump Parts.

We also sell New or Remanufactured Cub Cadet Hydraulic Pumps and Hydraulic Pumps for the following equipment, Ag Co/ Allis Hydraulic Pumps and Artic snowplows Hydraulic Pumps.
Hydrostatic Transmission Service offers New or Remanufactured Badger equipment Hydraulic Pumps and all Hydraulic Pumps for the following equipment, Barko Hydraulic Pumps or Barett Hydraulic Pumps.
For ten years we have offered New or Remanufactured Braun Hydraulic Pumps and all Bear Trac Hydraulic Pumps. Beau-Roc Hydraulic Pump or Bebo Hydraulic Pumps.
Looking for New or Remanufactured Bobcat Hydraulic Pumps and all Hydraulic Pumps for the following equipment, Bell cutters Pumps or Challanger Hydraulic Pumps we have them.

If you need New or Remanufactured Cub cadet Hydraulic Pumps and Hydraulic Pumps for the following equipment, Ditch Witch Hydraulic Pumps, we have them in stock.


When you Need High Performance Euclid, Elgin sweeper, Dixie logger or Dixie Chopper, hydraulic pumps we have them ,We also sell New or Remanufactured Ford New Holland, Fink, Ferris, Drexel, Presser Hydraulic Pumps and all Hydraulic Pumps for the following equipment,  Ingersol Rand, Hustler, Higgins, Hi-Way, Hi Ranger and more.
We invite you to Explore our Hydraulic Parts Page for New or Remanufactured Hydraulic Pumps for: JLG Hydraulic Pumps, M&W, Nissan, Kann, Maxon, Pabco, Krause, Mertz Inc., Phil Tram, Lantis, Mitsubishi, Prime Mover, London Concrete Machine.


We also have All Terrain Crane Hydraulic Pumps for the following equipment: Komatsu Hydraulic Pump or Komatsu All terrain Crane Hydraulic Pumps.
When you need the world’s leading brands for Industrial Cranes or New or Remanufactured Hydraulic Pumps for John Deere Hydraulic Pumps or Hydraulic Pump Repair, Manitou, Northwest Cranes, Kawasaki, Max Vision Snow Plows, Parkan, Kuhn, Mescbi, Pique, Lawn Boy, Morbark, Ravens, and all Terrain Crane Hydraulic Pumps, New Holland Excavator Hydraulic Pumps or New Holland All terrain Crane Hydraulic Pumps, call us first.


We offer a comprehensive range of Industrial Cranes and Hoists Pumps and also sell New or Remanufactured Excavator Hydraulic Pumps for Gallion, Galbreath, Fassi, Class, Davis, Bombadier, and All Terrain crane Hydraulic Pumps for the following equipment, Volvo Excavator Hydraulic Pump or Volvo All Terrain Crane Hydraulic Pumps.


HTS warehouses New or Remanufactured Excavator Hydraulic Pumps and Hydraulic Pumps for the following equipment, Gravely, Grassshopper, Heston, Haldex.


When you need New or Remanufactured Hydraulic Pumps and all Hydraulic Pump Repair for the following equipment, Long Hydraulic Pumps, New Way, Combines, Massey Ferguson, P&H, Komatsu, MEC, Petti Bone, Labre, Midland, Prentice, Link-Belt, National Crane, we have them.


We also sell New or Remanufactured Excavator Hydraulic Pumps and all terrain crane Hydraulic Pumps for the following equipment, Liebherr Excavator Hydraulic Pump or Liebherr All terrain Crane Hydraulic Pumps.
Excavator Hydraulic Pumps for New or Remanufactured Excavator Hydraulic Pumps and all terrain crane Hydraulic Pumps for the following equipment, Kawasaki Excavator Hydraulic Pump or Kawasaki All terrain Crane Hydraulic Pumps, is what we do.


For High Performance New or Remanufactured Excavator Hydraulic Pumps and all terrain crane Hydraulic Pumps for the following equipment, Koehring Excavator Hydraulic Pump or Koehring All terrain Crane Hydraulic Pumps, call us first.


We also sell New or Remanufactured Construction Excavator Hydraulic Pumps and all terrain crane Hydraulic Pumps for the following equipment, Samsung Excavator Hydraulic Pump or Samsung All terrain Crane Hydraulic Pumps.
For multiple lines of New or Remanufactured Excavator Hydraulic Pumps and all terrain crane Hydraulic Pumps for the following equipment, Terex Excavator Hydraulic Pump or Terex All terrain Crane Hydraulic Pumps, we have them in stock.


When you have a failure on New or Remanufactured Excavator Hydraulic Pumps and all terrain crane Hydraulic Pumps for the following equipment, Lorain Excavator Hydraulic Pump or Lorain All terrain Crane Hydraulic Pumps, let us be your one stop supplier.


To avoid down time, we also sell New or Remanufactured Excavator Hydraulic Pumps and all terrain crane Hydraulic Pumps for the following equipment, Tadano Excavator Hydraulic Pump or Tadano All terrain Crane Hydraulic Pumps.
Quick turnaround repair is what we offer for New or Remanufactured Excavator Hydraulic Pumps and all terrain crane Hydraulic Pumps for the following equipment, Grove Excavator Hydraulic Pump or Grove All terrain Crane Hydraulic Pumps.


To supply your needed New or Remanufactured Excavator Hydraulic Pumps and all terrain crane Hydraulic Pumps for the following equipment, American Excavator Hydraulic Pump or American All Terrain Crane Hydraulic Pumps, call us at 800-361-0068.


The majority of New or Remanufactured Excavator Hydraulic Pumps and all terrain crane Hydraulic Pumps for the following equipment, Demag Excavator Hydraulic Pump or Demag All terrain Crane Hydraulic Pumps, we have in stock.
On hard to find New or Remanufactured Excavator Hydraulic Pumps and all terrain crane Hydraulic Pumps for the following equipment, Warner-Swasey Excavator Hydraulic Pump or Warner-Swasey All terrain Crane Hydraulic Pumps, we can help.


Check our pricing on New or Remanufactured Excavator Hydraulic Pumps and all terrain crane Hydraulic Pumps for the following equipment, Krupp Excavator Hydraulic Pump or Krupp All terrain Crane Hydraulic Pumps.


Check our availability on New or Remanufactured Excavator Hydraulic Pumps and all terrain crane Hydraulic Pumps for the following equipment, Franna Mac Excavator Hydraulic Pump or Franna Mac All terrain Crane Hydraulic Pumps.
Check our website for New or Remanufactured Excavator Hydraulic Pumps and all terrain crane Hydraulic Pumps for the following equipment, P&H Excavator Hydraulic Pump or P&H All terrain Crane Hydraulic Pumps.


For price quote on New or Remanufactured Excavator Hydraulic Pumps and all terrain crane Hydraulic Pumps for the following equipment, Mantis Excavator Hydraulic Pump or Mantis All terrain Crane Hydraulic Pumps, call us at 662-680-8899.


HTS is here to help you with New or Remanufactured Excavator Hydraulic Pumps and all terrain crane Hydraulic Pumps for the following equipment, Drott Excavator Hydraulic Pump or Drott All terrain Crane Hydraulic Pumps.
Please call us first for New or Remanufactured Excavator Hydraulic Pumps and all terrain crane Hydraulic Pumps for the following equipment, Bucyrus Erie Excavator Hydraulic Pump or Bucyrus Erie All terrain Crane Hydraulic Pumps.
Let us quote you on your New or Remanufactured Hydraulic Pumps and all terrain crane Hydraulic Pumps for the following equipment, Gallion Excavator Hydraulic Pump or Gallion All terrain Crane Hydraulic Pumps.


HTS offers competitive pricing for New or Remanufactured Excavator Hydraulic Pumps and all terrain crane Hydraulic Pumps for the following equipment, PPM ATT Excavator Hydraulic Pump or PPM ATT All terrain Crane Hydraulic Pumps.


On New or Remanufactured Excavator Hydraulic Pumps and all terrain crane Hydraulic Pumps for the following equipment, Ban Tano Excavator Hydraulic Pump or Ban Tano All terrain Crane Hydraulic Pumps, we are very competitive.
HTS services and sells New or Remanufactured Excavator Hydraulic Pumps and all terrain crane Hydraulic Pumps for the following equipment, Yanmar Excavator Hydraulic Pump or Yanmar All terrain Crane Hydraulic Pumps.


Repaired and New or Remanufactured Excavator Hydraulic Pumps and all terrain crane Hydraulic Pumps for the following equipment: Rudco Hydraulic Pumps, Swenson, West Coast, Tam Rock Loaders, Sheffer, Telsta, Yale, Sky Jack, Tiger Cat, Trident Marine Cranes, SwapLoader, Spreader Volvo, Wiers, Tarrant, Work Saver, Sky Hook, THS, Sno-Way, Snowman, Versatile, Schlagel, Tail-Gator, Sellick, Woods, Sky Hoist, Thermaso, Yanmar, Timber Jack, Tymco, Samsung, Tafco, Western Snow Plows, Tarco, Shupak, Terex, Yamaha, Snapper, Snorkel, Spiker Buckeye, Stagg.


XCMG Excavator Hydraulic Pump or XCMG All terrain Crane Hydraulic Pumps are available.


In Stock New or Remanufactured Excavator Hydraulic Pumps and all terrain crane Hydraulic Pumps for the following equipment, Manitowoc Excavator Hydraulic Pump or Manitowoc All terrain Crane Hydraulic Pumps.

Cub Cadet Hydraulic Pumps are designed and engineered for peak hydraulic performance. Each Cub Cadet hydraulic pump is designed to deliver Cub Cadet hydraulic pump pressure at a fingertip, joystick application. Cub Cadet has developed a Cub Cadet hydraulic pump that can create a positive bottom line for your company when using the Cub Cadet hydraulic pump system in your heavy equipment. If there is a failure in your hydraulic pump system, your hydraulic pump can easily be replaced with a new Cub Cadet hydraulic pump or your Cub Cadet hydraulic pump can be repaired with new Cub Cadet hydraulic pump parts. We also offer an exchange program where you send your failed Cub Cadet hydraulic pump core in, and we can send you a new or remanufactured Cub Cadet hydraulic pump.


All of our Cub Cadet excavator hydraulic pumps carry a one year warranty and offer a full money back guarantee. We usually can ship your Cub Cadet excavator hydraulic pump in three days or so.

Cub Cadet excavator hydraulic pumps are designed to last a lengthy period of time when paired with the proper maintenance.

Visit Our eBay Store HERE.

Visit Our Hydraulic Parts Store HERE.

Hydrostatic Transmission Service, LLC
1644 Eason Blvd Bldg D
Tupelo, MS 38801
Toll: 800-361-0068 Phone (662) 680-8899 Fax (662) 680-8097

EXCAVATOR HYDRAULIC AND HYDROSTATIC PUMP WARRANTY
EXCAVATOR HYDRAULIC-HYDROSTATIC PUMP WARRANTY INSTRUCTIONS
Hydrostatic Transmission Service, LLC warrants our excavator hydraulic-hydrostatic repaired pump or motor to be free of any defects in workmanship for a period of one (1) year from the date of installation if the following conditions are met by the customer:
A. The excavator hydraulic-hydrostatic pump reservoir must be cleaned out with diesel fuel or solvent and clean rags, then blown out with air.
B. All excavator hydraulic-hydrostatic pump lines must be filled with diesel fuel or solvent and blown out backwards with air.
C. All excavator hydraulic-hydrostatic pump fittings must have replacement o-rings installed.
D. The excavator hydraulic-hydrostatic pump oil cooler must be removed from the machine and taken to a company that can adequately clean and core it out by certified a radiator shop. The oil cooler must be placed in vat and cored out, do not place in acid vat as fins are made of aluminum. After removing from vat, use cheese cloth on the bottom output and force naptha or diesel from the top down with force to check again for any debris. Shake unit, if any rattling at all, purchase a new oil cooler.  A copy of this receipt must be forwarded to our company so that we can put it on file. High pressure hosing and/or flushing does not qualify for warranty procedure. ***IF THERE HAS BEEN CATASTROPHIC FAILURE AND/OR THE OIL COOLER CANNOT BE 100% CLEANED AND FREE OF DEBRIS, THEN THE OIL COOLER MUST BE REPLACED WITH A NEW OIL COOLER.***
E. All filters must be replaced.
F. All excavator hydraulic-hydrostatic pump oil must be replaced, preferably with a 30 weight non-foaming rust and oxide oil.
G. The excavator hydraulic-hydrostatic pump or motor must be physically charged with oil before connecting the excavator hydraulic-hydrostatic pump lines back to the unit, by filling the cavity of the units up with a funnel and oil.
H. Attach all lines, fill up reservoir with oil, start unit for 20 seconds and cut off. Then, refill with oil again.
I. Any deviation from the above procedures will automatically void our warranty completely.
J. If all the above conditions are met, we unconditionally warrant our product for one full year, parts only. This does not include labor to take off and put on.
I, the customer, have read and fully understand the above procedures and certify that all procedures have been completed as requested herein.
______________________________________ ____________________________________
Customer or Company authorized personnel signature Date
____________________________________________________ __________________________________________________
Customer or Company authorized personnel printed name Title
____________________________________________________ __________________________________________________
Company Name Invoice Number

**Signed, Dated Original Copy of this should be returned to Hydrostatic Transmission Service, LLC, Attn: Warranty Dept, 1644 Eason Blvd, Bldg D, Tupelo, MS 38801 or Email to [email protected]



Sours: https://www.hydrostaticpumprepair.com/html/cub_cadet_eq.html


1662 1663 1664 1665 1666
